Application of Eaton Hydraulic System to Medium Hydraulic Excavator



Eaton Corporation is an American multinational power management company aiming to providing customers with effective, safe and sustainable solutions for the management of electrical, hydraulic and mechanical power. Its main products are hydraulic motor, hydraulic valves, hydraulic pumps, hydraulic cylinders, hydraulic differentials and hydraulic power units.



Excavators, as widely used construction machinery, have strict requirements on hydraulic system. Eaton has been committed to providing system solutions for customers in this field. In 2010, it launched Duraforce load sensing hydraulic system for excavators. In 2012, it fully acquired JEIL, The First Oil Pressure Company in South Korea, and fully entered the excavator hydraulic market.





As a well-known manufacturer of hydraulic products in South Korea, The First Oil Pressure Company focuses on the development and manufacturing of excavator related products and it provides supporting products for well-known excavator enterprises in China, South Korea and Japan. Its products cover the main pump, main valve, rotary drive assembly and moving drive assembly (hydraulic motor and planetary reducer) used in 1.5 to 50 tons excavators. After the acquisition, Eaton will further improve the quality of JEIL products by using its stringent production management and quality control system to enhance the potential value of products for customers.



As a typical representative of medium-sized excavators, 20-ton excavators are widely used in engineering construction, water conservancy and electric power engineering, mining and other industries. Load sensitive, negative flow and positive flow control are three typical hydraulic systems in medium excavators. Among them, negative flow control system is the mainstream technology in the medium excavator market.



In order to meet the diversified product needs of customers, Eaton officially released the load sensitive Duraforce hydraulic control complete set in 2013.



Eaton’s JMF series rotary drive assemblies are widely used in excavators ranging from 3.5 tons to 36 tons, and their reliability has been proven by the market for many years. Relative displacement (the product of motor displacement and reducer reduction ratio) ranges from 350cc/rev to 5500cc/rev, with the highest rated pressure up to 320bar and the highest peak pressure up to 385bar (rated and peak pressure will be different according to motor displacement, see Eaton sample for details), and the maximum output torque ranges from 1000NM to 25000NM.



For the JMF151 rotary drive assembly, used on the 20-ton excavator, Eaton has redesigned the JMF151 rotary drive assembly on the basis of the original product, so that the reliability and durability of the product is better than other products in the industry.



At the same time, on the background of global environmental protection, Eaton uses its global R&D resources to continuously explore new concepts, new technology application in the field of excavator and has successfully developed a full hydraulic hybrid system. The hydraulic system of the patent technology has successfully passed the prototype test in global famous manufacturers. It is able to meet the clients' demand for energy conservation and emissions reduction.
