What Is Hydraulic Hose Fitting?



The hydraulic pipe joints is a kind of hydraulic system which connects different hydraulic components (pump, transmission pipeline, directional valve, hydraulic shutoff valve, hydraulic motor, hydraulic cylinder fittings, and some auxiliary components, such as liquid level gauge, thermometer, pressure gauge, etc.) to form a closed circuit hydraulic system, which is a part of the connection. There are also many systems like the hydraulic transmission system.



In the hydraulic system, whether it is a metal pipe joint or a hose joint, there is a chance to produce leakage. For the hydraulic ferrule fittings, most of the pipe is subject to a large external force or impact force, which makes the ferrule lose or the end face of the pipe deforms and causes leakage. At this time, it is necessary to check the ferrule to make sure whether the cutting edge is defective, whether the pipe end is in good condition, and the compression degree of the ferrule nut, etc. The external force of the pipe should be eliminated. Most of the flared pipe joints leak due to excessive expansion, unqualified quality, or repeated disassembly, resulting in expansion deformation or cracks. In this case, the front end can be cut off for re-expansion. If the male and female cone top pressure is used for sealing, the leakage is mostly due to the damage of the two conical surfaces, and the grinding sand can be used to grind the conical surface. For the leakage at the pipe joint using oil-resistant rubber plate, wool felt, mild steel paperboard, combined sealing gasket or sealant, no matter what the material is, the sealing parts shall be checked for damage, deformation, aging, and excessive roughness, and then corresponding measures shall be taken.

If you want to make the hdy hose fitting achieve an optimal situation, you must take these pipeline layout requirements into account.



(1) The pipeline should avoid high-temperature radiation and cooling water spray and other places with too high or too low temperature, especially the hydraulic rubber hose.



 (2) the pipe laying should not affect the operation of the main engine and other equipment and should be safe and reliable, convenient for work, observation, and maintenance.



(3) Pipe layout should be horizontal and vertical, neat, and beautiful. As far as possible, there are few bends or small angle bends, and a large circular arc is used to reduce the oil flow resistance.



4) In case of installation conflict, the small pipe shall give way to the large pipe, and the low-pressure pipe shall give way to the high-pressure pipe.



(5) When the pipelines cross each other, they should be separated by a certain distance.

(6) The joints of parallel pipes shall be staggered to avoid affecting the installation and disassembly.

(7) In order to facilitate the disassembly and cleaning of the pipeline, the movable joint should be properly installed, but it should be used less to reduce the possibility of leakage.

As Jazzy has a wide range of products, hydraulic hose fitting is one of those. They have their own production base so that they are directly responsible for the production and sales of their products. Therefore, clients do not need to worry about the quality like rubber hydraulic plugs.
